Toy Blow Molding Machine

Name: Toy Blow Molding Machine
Brand: Alliedway India
Price: 6500000 INR
Availability: InStock

6500000 INR/Unit

Get a Price/Quote

Product Details:

Product Type industrial
General Use Manufacturing plastic toys and hollow plastic products
Material Mild Steel, Stainless Steel (Frame), Mold Steel
Capacity 100 Ltr
Weight (kg) 1200 kg
Type Horizontal Type
Computerized No
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Toy Blow Molding Machine Price And Quantity

Minimum Order Quantity 1 Unit
Price 6500000 INR/Unit

Electric Consumption Approx. 16 kWh/day
Maximum Product Diameter 110 mm
Plasticizing Capacity 55 kg/hr
Air Compressor Required 7.5 HP or above
Lubrication Automatic Lubrication System
Control System PLC Control Panel
Max. Mold Width 280 mm
Cooling System Water Cooling
Maximum Product Height 300 mm
Heating Zones 4
Min. Mold Thickness 110 mm
Installation Support Available
Screw Diameter 60 mm
Screw L/D Ratio 24:1

Toy Blow Molding Machine Product Specifications

Type Horizontal Type
Capacity 100 Ltr
Product Type industrial
Clamping Force 40 kN
Infrared Heater Included
General Use Manufacturing plastic toys and hollow plastic products
Automatic Semi-Automatic
Material Mild Steel, Stainless Steel (Frame), Mold Steel
Mould Stroke 150 mm
Weight (kg) 1200 kg
Power 120Kw Watt (w)
Blow Moulding Type Extrusion Blow Molding
Dimension (L*W*H) 5.5mx2.8mx5m Meter (m)
Low Pressure Air Displacement 0.7m3/min at 7kg/cm2
Feature High Efficiency, Robust Construction, Easy Operation, Low Maintenance
Clamping Stroke 150 mm
Stretching Stroke 160 mm
Computerized No
Voltage 380V / 50Hz, 3 Phase
Color Blue & White (Standard)
Cavity Quantity 2 Cavity (customizable)
High Pressure Air Displacement 1.2m3/min at 30kg/cm2

Electric Consumption Approx. 16 kWh/day
Maximum Product Diameter 110 mm
Plasticizing Capacity 55 kg/hr
Air Compressor Required 7.5 HP or above
Lubrication Automatic Lubrication System
Control System PLC Control Panel
Max. Mold Width 280 mm
Cooling System Water Cooling
Maximum Product Height 300 mm
Heating Zones 4
Min. Mold Thickness 110 mm
Installation Support Available
Screw Diameter 60 mm
Screw L/D Ratio 24:1

Product Description

Discover a wondrous Deal on our Toy Blow Molding Machine, crafted for unbeatable efficiency at an unmatchable price. This semi-automatic marvel, decorated in striking blue and white, features a 60 mm screw diameter, robust 40 kN clamping force, and customizable two-cavity design. Its PLC control panel and automatic lubrication ensure easy operation and low maintenance. With a plasticizing capacity of 55 kg/hr and a 100 Ltr output, this powerhouse streamlines toy production. Order now for remarkable results and dependable installation support, backed by our trusted manufacturing expertise in India.

Application Areas & Usage of Toy Blow Molding Machine

The Toy Blow Molding Machine is extensively used in manufacturing plastic toys and hollow plastic goods utilizing extrusion blow molding technology. It is suitable for large-scale production thanks to its high efficiency and robust construction. Perfect for factories producing children's toys, promotional items, and decorative plastic products, its versatile design supports both mild and stainless steel materials. The user-friendly PLC Control Panel ensures operators can handle batch or customized production effortlessly, ensuring consistent, high-quality output in diverse industrial environments.

Market Focus, Export Reach & Quick Delivery

Serving both the Main Domestic Market across India and key Export Markets worldwide, our Toy Blow Molding Machine is in high demand for its reliability and performance. We offer quick dispatch to ensure your production stays on schedule, complemented by superior transportation and delivery rates. Our streamlined logistics system ensures prompt delivery, from small units to large-scale orders, so you receive dependable service and timely setup. As manufacturers and suppliers, we guarantee consistent availability and responsive customer support every step of the way.

FAQ's of Toy Blow Molding Machine:

Q: How does the Toy Blow Molding Machine facilitate the manufacturing process of plastic toys?

A: The machine uses extrusion blow molding with a powerful screw and well-regulated heating and cooling systems to mold hollow plastic toys and products quickly and efficiently, ensuring optimal shape and strength.

Q: What are the main features that make this blow molding machine unique?

A: Its unmatchable efficiency, robust construction, semi-automatic operation, automatic lubrication, and PLC control panel make it easy to operate and maintain. Customizable cavities and a high clamping force add to its versatility.

Q: Where can this Toy Blow Molding Machine be used most effectively?

A: It is ideal for plastic toy factories, manufacturing plants for hollow plastic products, and other industries needing high-volume plastic blow molding with precise results.

Q: What is the installation support provided for the machine?

A: We offer comprehensive installation support, ensuring the machine is correctly set up and operators are properly trained for safe and efficient usage.

Q: When can buyers expect delivery after placing an order?

A: Quick dispatch is available, with delivery times depending on destination and order size. Our efficient transportation ensures timely arrival, typically within the quoted timeframe.

Q: How does the PLC Control Panel improve the operation of the machine?

A: The PLC Control Panel simplifies machine operation by allowing precise adjustments, monitoring performance, and automating key processes, resulting in superior product quality and reduced downtime.
